空心杯有刷电机系列
| 型号 | 直径（mm） | 空载电流（mA） | 空载转速（rpm） | 堵转扭力(mNm) | 重量(g) | 长度(mm) | 说明书 |
| 2232R | 22 | 114 | 6500 | 34.11 | 60.25 | 32 |
|
| 2225R | 22 | 35 | 4900 | 11.46 | 43.8 | 25 |
|
| 1725R | 17 | 27 | 9600 | 16.45 | 26.9 | 25 |
|
| 1723R | 16.9 | 32 | 8100 | 11.30 | 25 | 23.5 |
|
| 1722R | 17.4 | 10 | 19200 | 29.2 | 26.3 | 22.2 |
|
| 1718R | 17.4 | 60 | 16500 | 13 | 20.3 | 18.2 |
|
| 1715R | 17.4 | 60 | 17500 | 7.4 | 16.10 | 15.2 |
|
| 1642R | 16 | 42 | 5800 | 16.69 | 30 | 42 |
|
| 1625R | 16 | 18 | 6700 | 6.8 | 24.35 | 25 |
|
| 1620R | 16 | 10 | 4680 | 2.40 | 26.8 | 20 |
|
| 1515R | 15 | 10 | 13100 | 3.79 | 11.25 | 15.2 |
|
| 1332R | 13 | 70 | 14000 | 15.2 | 20.9 | 32 |
|
| 1218R | 12 | 10 | 16800 | 0.70 | 9.2 | 18 |
|
| 1215R | 12 | 60 | 18360 | 3.6 | 6.5 | 15 |
|
| 1213R | 12 | 65 | 27400 | 0.50 | 5.8 | 13 |
|
| 1020R | 10 | 13 | 6800 | 0.5 | 7.0 | 20 |
|
| 1015R | 10 | 38 | 17000 | 0.5 | 4.65 | 15 |
|
| 2642RC(碳刷） | 26mm | 40 | 9400 | 251.10 | 70g | 43mm |
|
| 1730RC | 17mm | 160 | 11250 | 34.7 | 28g | 30mm |
|
| 1615RB | 16 | 65 | 20076 | 5.3 | 15g | 15 |
|
| 1328RB | 13mm | 60 | 11300 | 10.4 | 17.8g | 28 |
|
| 1320RB | 13 | 25 | 10750 | 5.0 | 16g | 20 |
|
| 2607R | 26 | 15 | 10000 | 10.80 | 20.6 | 07 |
|
| 2230RC | 22 | 130 | 12630 | 31.4 | 58 | 30 |
|
| 3265RC | 32 | 80 | 5900 | 428.5 | 225 | 65 |
|
| 3553RC | 35 | 260 | 9000 | 336.2 | 217.4 | 53 |
|
| 3570RC | 35 | 140 | 4500 | 690.9 | 319 | 70 |
|
| 4070RC | 40 | 130 | 7250 | 1513.2 | 403.9 | 70 |
|
